Character of 4H-N SiC
- use SIC Monocrystal to manufacture
- customization is allowed by design drawings
- high performance, high resistivity and low leakage currents
- 9.2 Mohs high hardness, just behind diamond
- widely used in high-tech areas, like power electronics, LEDs and
sensors
Brief introduction of 4H-N SiC
Silicon carbide (SiC) is a semiconductor material made of silicon
and carbon.
It has excellent hardness and strength, making it very durable.
SiC is known for its excellent thermal conductivity, which allows
it to efficiently dissipate heat, making it ideal for high-power
and high-temperature applications.
One of its main properties is a wide bandgap, which enables devices
to operate at higher voltages, temperatures, and frequencies than
silicon.
SiC also has high electron mobility, which helps enable faster and
more efficient electronic devices.
Its chemical stability and resistance to oxidation make it ideal
for harsh environments.
SiC is widely used in power electronics, where efficiency and
durability are critical, as well as high-frequency devices, LEDs,
and as a substrate for the growth of other semiconductor materials
such as gallium nitride (GaN).
Its properties make it a valuable material in advanced electronic
applications.
More details about 4H-N SiC
*More details will be shown in the following table.
| 6-inch Diameter 4H N-type Silicon Carbide Substrate Specification |
| SUBSTRATE PROPERTY | Production Grade | Dummy Grade |
| Diameter | 150 mm ± 0.1 mm |
| Surface Orientation | off-axis: 4° toward <11-20> ± 0.5° |
| Primary Flat Orientation | <1-100> ± 5.0˚ |
| Primary Flat Length | 47.5 mm ± 2.0 mm |
| Resistivity | 0.015~0.028Ω·cm | ≤0.1Ω·cm |
| Thickness | 350.0 μm ± 25.0 μm or 500.0 μm ± 25.0 μm |
| TTV | ≤15 μm | ≤25 μm |
| BOW | ≤30 μm | ≤50 μm |
| Warp | ≤40 μm | ≤60 μm |
| Surface Finish | Double Side Polish, Si Face CMP (chemical polishing) |
| Surface Roughness | CMP Si Face Ra≤0.5 nm, C Face Ra≤1 nm | N/A |
| Note: Customerized specifications other than the above parameters
are acceptable. |
Other samples of 4H-N SiC
*If you have further requirements, we can manufacture the
customized ones.
