200mm 300mm length sapphire bar with groove 0.5mm depth for optical
fiber
Applications of Sapphire crystal glass: Sapphire Washers, Sapphire
Windows, Sapphire Bearings, Sapphire Rods, Sapphire Tubes, Ruby
sapphire wafer, dome sapphire, Sapphire insulation Film, Sapphire
ball lens, Sapphire/ruby ball
●Aircraft windows●Submarine windows
●FLIR●Medical/Life Sciences
●Industrial OEM● Intelligence, surveillance &
reconnaissance(ISR)
|
| 8-400mm |
| +0/-0.05mm |
Surface quality(scratch&dig) | 40/20 |
| λ/10per@633nm |
| ＞85%,＞90% |
| ±2''-±3'' |
| 0.1-0.3mm |
| AR/AF/upon customer request |
|
Sapphire characteristics
| Materials characteristics |
| Item | B270 | CaF2 | Ge | MgF2 | N-BK7 | Sapphire | Si | UV Fused Sillca | ZnSe | ZnS |
| Refractive index(nd) | 1.523 | 1.434 | 1.003 | 1.413 | 1.517 | 1.768 | 3.422 | 1.458 | 2.403 | 2.631 |
| Coeffcient of dispersion(Vd) | 58.5 | 95.1 | N/A | 106.2 | 64.2 | 72.2 | N/A | 67.7 | N/A | N/A |
| Density(g/cm3) | 2.55 | 3.18 | 5.33 | 3.18 | 2.46 | 3.97 | 2.33 | 2.20 | 5.27 | 5.27 |
| TCE(μm/m℃) | 8.2 | 18.85 | 6.1 | 13.7 | 7.1 | 5.3 | 2.55 | 0.55 | 7.1 | 7.6 |
| Soften Temperature(℃) | 533 | 800 | 936 | 1255 | 557 | 2000 | 1500 | 1000 | 250 | 1525 |
| Knoop hardness(kg/mm2) | 542 | 158.3 | 780 | 415 | 610 | 2200 | 1150 | 500 | 120 | 120 |
About Our Company ZMKJ Sapphire Process
ZMKJ locates in the city of Shanghai, Which is the best city of
China, and our factory is founded
in Wuxi city in 2014.
We specialize in processing a varity of materials into wafers,
substrates and custiomized optical
glass parts as like sapphire, sic, quartz.components widely used in
electronics, optics, optoelectronics
and many other fields. We also have been working closely with many
domestic and oversea universities, research institutions and
companies, provide customized products and services for their
R&D projects.
It's our vision to maintaining a good relationship of cooperation with our all
customers by our good reputatiaons.
3.0 Sapphire sample in detail
4.We can supply professional customized service in time and provide
cooperation and support of new product development and technology
appliance by other semiconducting material products.
6.0 FAQ –
Q: What you can supply logistics and cost?
(1) We accept DHL, Fedex, TNT, UPS, EMS, SF and etc by FOB
delivery.
If you have your own express number, it's great.
Q: How to pay?
50％ deposit ,50％ before delivery byT/T, Paypal, West Union,
MoneyGram,
Secure payment and Trade Assurance on and etc..
Q: What's the delivery time?
(1) For the standard products such as ball lens,
substrates,windows,
For inventory: the delivery is 5 workdays after order.
For customized products: the delivery is 2 or 3 workweeks after
order.
Q: What's the MOQ?
(1) For inventory, the MOQ is 5pcs.
(2) For customized products, the MOQ is 10pcs-30pcs.
