2“4”6"quartz optical wafer, GE fused quartz substrates for
SEMI,quartz optical glass plate for window, quartz optical glass
window, GE fused quartz optical glass lens, quartz optical
window,2“4”6"quartz optical wafer, Fused quartzsubstrate wafer
1. Product Description
1. high temperature resistant, Quartz Slab Or Optical Quartz Glass
Plate Or Quartz Substrate,
Fused Quartz Glass can work under 1200°C continuously,and in short
time can even work under 1450°C,
its softening temperature is 1650°C,and the melting temperature is
1750-1800°C.
2. Corrosion resistant, Except hydrofluoric acid, Quartz Plate Of
Optical Grade do not react with
any acid and base except hydrofluoric acid.the stability is
30 tims of the ceramic,and 150 times of stainless steel .
3. Excellent thermal shock stability
4. High transmission to 85%
5. Electric insulation ,it is 10000 times of usual glass
Property | Typical Values | Property | Typical Values |
Density | 2.2x103 kg/m3 | Electrical Resistivity | 7x107 ohm cm (350°C) |
Hardness | 5.5 - 6.5 Mohs' Scale 570 | Index of Refraction | 1.4585 |
Design Tensile Strength | 4.8x107 Pa (N/m2) | Strength | 5x107 V/m |
Bulk Modulus | 3.7x1010 Pa (5.3x106 psi) | transmittance rate | 85% |
Rigidity Modulus | 3.1x1010 Pa (4.5x106 psi) | Sonic Attenuation | Less than 11 db/m MHz |
Softening Point | 1683°C | Helium | 210x10-10 |
Annealing Point | 1215°C | Hydrogen | 21x10-10 |
Strain Point | 1120 °C | Deuterium | 17x10-10 |
3. Product Size Description:
1. Translucence Quartz Glass thickness 0.5-30mm, Length: 25-200mm, .Width: 25-200mm
2. Thickness Tolerance: +/-0.2mm
3. Raw Material: Quartz , SiO2: >=99.99%
4. Color : Clear , Translucence.
5. Surface quality :40/20 60/40 80/50
6. Transmittance >90%
7. Sharpe: Square ,round, Can make the size and sharp according to
customer's require.
4. Process Step For Optical Lens
5. FAQ
Q: What you can supply logistics and cost?
(1) We accept DHL, Fedex, TNT, UPS, EMS, SF and etc by FOB.
Q: What's the delivery time?
(1) For the standard products such as ball lens, powell lens and
collimator lens:
For inventory: the delivery is 5 workdays after order.
For customized products: the delivery is 2 or 3 workweeks after
order.
Q: How to pay?
100％T/T before delivery, Paypal, West Union, MoneyGram.
Q: What's the MOQ?
(1) For inventory, the MOQ is 25pcs for 2-6inch wafer.
(2) For customized products, the MOQ is 50pcs.
It depends on quantity and technics
6. About Our Factory.
Shanghai famous trade co.,ltd. is established in 2013, and our
factory is established in 2014 Wuxi city.
Our team is a professional manufacturer and exporter that is
concerned with the semiconductor substrates providing ,optical
wafer producting .We are located in shanghai with convenient
transportation access.All of our products comply with international
quality standards and are greatly appreciated in a variety of
different markets throughout the world. We have over 30
employees,Our well-equipped facilities and excellent quality
control throughout all stagesof production enables us to guarantee
total customer satisfaction.
As a result of our high quality products and outstanding customer
service, we have gained a global sales network reaching If you are
interested in any of our products or would like to discuss a custom
order, please feel free to contact us. We are looking forward to
forming successful business relationships with new clients around
the world in the near future.
